A replication-defective tick-borne encephalitis virus generated by NS1 <i>trans</i>-complementation confers robust protective efficacy

Ji Zhang; Qiu-Yan Zhang; Zhe-Rui Zhang; Ya-Nan Zhang; Hong-Qing Zhang; Cheng-Lin Deng; Bo Zhang

doi:10.1016/j.virs.2026.07.010

August 2026

Citation: Ji Zhang, Qiu-Yan Zhang, Zhe-Rui Zhang, Ya-Nan Zhang, Hong-Qing Zhang, Cheng-Lin Deng, Bo Zhang. A replication-defective tick-borne encephalitis virus generated by NS1 trans-complementation confers robust protective efficacy .VIROLOGICA SINICA, 2026, 41(4) : 937-946. http://dx.doi.org/10.1016/j.virs.2026.07.010

A replication-defective tick-borne encephalitis virus generated by NS1 trans-complementation confers robust protective efficacy

State Key Laboratory of Virology and Biosafety, Wuhan Institute of Virology, Wuhan 430071, China

Corresponding author: Cheng-Lin Deng, dengcl@wh.iov.cn
Bo Zhang, zhangbo@wh.iov.cn
Received Date: 04 January 2026
Accepted Date: 28 July 2026
Available online: 30 July 2026

Abstract

Tick-borne encephalitis virus (TBEV) poses a severe threat to public health, causing neurological disorders with high morbidity and mortality in endemic regions. Therefore, developing safe and effective strategies for TBEV vaccines has long been a focus of attention. Herein, leveraging our well-established NS1 trans-complementation platform, we successfully constructed a high-titer replication-defective TBEV (TBEV-△NS1) using the BHK-21 cell line stably expressing Omsk hemorrhagic fever virus (OHFV) NS1 (designated BHK_NS1). Retention of the NS1 deletion in TBEV-△NS1 was confirmed by continuous passaging in BHK_NS1 cells, as no replicative virus was detected in naive BHK-21 cells. The safety profile of TBEV-△NS1 was further validated, as administration of a high dose of TBEV-△NS1 to ICR mice did not induce any clinical symptoms. Notably, TBEV-△NS1 conferred complete protection against lethal wild-type (WT) TBEV challenge in ICR mice, whereas non-immunized control mice exhibited 100% mortality, significant weight loss, and viremia. This protective efficacy is tightly correlated with robust humoral and cellular immune responses, as demonstrated by the induction of high titers of TBEV-specific IgG, neutralizing antibodies, and IFN-γ-secreting CD8⁺ T cells following a single immunization. Collectively, our findings provide a proof-of-concept for the NS1 trans-complementation platform in TBEV vaccine development.
- Tick-borne encephalitis virus (TBEV)
- , NS1
- , Trans-complementation strategy
- , Vaccine

Electronic Supplementary Material

10.1016j.virs.2026.07.010-ESM.docx
References
1. Andersson CR, Vene S, Insulander M, Lindquist L, Lundkvist A, Gunther G. 2010. Vaccine failures after active immunisation against tick-borne encephalitis. Vaccine, 28: 2827-2831.
2. Arroyo J, Miller C, Catalan J, Myers GA, Ratterree MS, Trent DW, Monath TP. 2004. ChimeriVax-West Nile virus live-attenuated vaccine: preclinical evaluation of safety, immunogenicity, and efficacy. J Virol, 78: 12497-12507.
3. Avirutnan P, Hauhart RE, Somnuke P, Blom AM, Diamond MS, Atkinson JP. 2011. Binding of flavivirus nonstructural protein NS1 to C4b binding protein modulates complement activation. J Immunol, 187: 424-433.
4. Baldwin WR, Giebler HA, Stovall JL, Young G, Bohning KJ, Dean HJ, Livengood JA, Huang CY. 2021. Single dose of chimeric dengue-2/Zika vaccine candidate protects mice and non-human primates against Zika virus. Nat Commun, 12: 7320.
5. Berens-Riha N, Andries P, Aerssens A, Ledure Q, Van Der Beken Y, Heyndrickx L, Genbrugge E, Tsoumanis A, Van Herrewege Y, Arien KK, Van Innis M, Vanbrabant P, Soentjens P. 2024. Five accelerated schedules for the tick-borne encephalitis vaccine FSME-Immun^® in last-minute travellers: an open-label, single-centre, randomized controlled pilot trial. J Travel Med, 31: taad053.
6. Biering SB, Akey DL, Wong MP, Brown WC, Lo NTN, Puerta-Guardo H, Tramontini Gomes de Sousa F, Wang C, Konwerski JR, Espinosa DA, Bockhaus NJ, Glasner DR, Li J, Blanc SF, Juan EY, Elledge SJ, Mina MJ, Beatty PR, Smith JL, Harris E. 2021. Structural basis for antibody inhibition of flavivirus NS1-triggered endothelial dysfunction. Science, 371: 194-200.
7. Carpio KL, Barrett ADT. 2021. Flavivirus NS1 and Its Potential in Vaccine Development. Vaccines (Basel), 9: 622.
8. Chang GJ, Hunt AR, Davis B. 2000. A single intramuscular injection of recombinant plasmid DNA induces protective immunity and prevents Japanese encephalitis in mice. J Virol, 74: 4244-4252.
9. Chao CH, Wu WC, Lai YC, Tsai PJ, Perng GC, Lin YS, Yeh TM. 2019. Dengue virus nonstructural protein 1 activates platelets via Toll-like receptor 4, leading to thrombocytopenia and hemorrhage. PLoS Pathog, 15: e1007625.
10. Chew BLA, Ngoh ANQ, Phoo WW, Chan KWK, Ser Z, Tulsian NK, Lim SS, Weng MJG, Watanabe S, Choy MM, Low J, Ooi EE, Ruedl C, Sobota RM, Vasudevan SG, Luo D. 2024. Secreted dengue virus NS1 from infection is predominantly dimeric and in complex with high-density lipoprotein. Elife, 12: RP90762.
11. Chidumayo NN, Yoshii K, Kariwa H. 2014. Evaluation of the European tick-borne encephalitis vaccine against Omsk hemorrhagic fever virus. Microbiol Immunol, 58: 112-118.
12. Ecker M, Allison SL, Meixner T, Heinz FX. 1999. Sequence analysis and genetic classification of tick-borne encephalitis viruses from Europe and Asia. J Gen Virol, 80 ( Pt 1): 179-185.
13. Glasner DR, Puerta-Guardo H, Beatty PR, Harris E. 2018. The Good, the Bad, and the Shocking: The Multiple Roles of Dengue Virus Nonstructural Protein 1 in Protection and Pathogenesis. Annu Rev Virol, 5: 227-253.
14. Hainz U, Jenewein B, Asch E, Pfeiffer KP, Berger P, Grubeck-Loebenstein B. 2005. Insufficient protection for healthy elderly adults by tetanus and TBE vaccines. Vaccine, 23: 3232-3235.
15. Hehner J, Schneider L, Woitalla A, Ott B, Vu KCT, Schobel A, Hain T, Schwudke D, Herker E. 2024. Glycerophospholipid remodeling is critical for orthoflavivirus infection. Nat Commun, 15: 8683.
16. Hoenninger VM, Rouha H, Orlinger KK, Miorin L, Marcello A, Kofler RM, Mandl CW. 2008. Analysis of the effects of alterations in the tick-borne encephalitis virus 3'-noncoding region on translation and RNA replication using reporter replicons. Virology, 377: 419-430.
17. Holzmann H, Vorobyova MS, Ladyzhenskaya IP, Ferenczi E, Kundi M, Kunz C, Heinz FX. 1992. Molecular epidemiology of tick-borne encephalitis virus: cross-protection between European and Far Eastern subtypes. Vaccine, 10: 345-349.
18. Khlusevich Y, Kravchuk B, Kechin A, Stepanova A, Emelyanova L, Khachatryan S, Tikunova N, Matveev A. 2025. TBEV NS1 Induces Tissue-Specific Microvascular Endothelial Cell Permeability by Activating the TNF-α Signaling Pathway. Int J Mol Sci, 26: 5311.
19. Kubinski M, Beicht J, Zdora I, Biermann J, Puff C, Gerlach T, Tscherne A, Baumgartner W, Osterhaus A, Sutter G, Prajeeth CK, Rimmelzwaan GF. 2023. A recombinant Modified Vaccinia virus Ankara expressing prME of tick-borne encephalitis virus affords mice full protection against TBEV infection. Front Immunol, 14: 1182963.
20. Kulatay T, Sedova E, Shevtsov A, Zauatbayeva G, Ingirbay B, Keyer V, Shakhmanova Z, Zhumabekova M, Abduraimov Y, Rsaliyev A, Sikhayeva N, Kozlova I, Zaripov M, Shustov AV. 2025. Synthetic genomics-based generation of the tick-borne encephalitis virus Siberian subtype prototype strain and E51K-attenuated variant for vaccine development and antiviral screening. Virol Sin, 40: 812-821.
21. Li N, Deng CL, Li Q, Chen XL, Zhang B, Ye HQ. 2023. A safe replication-defective Zika virus vaccine protects mice from viral infection and vertical transmission. Antiviral Res, 211: 105549.
22. Li N, Zhang YN, Deng CL, Shi PY, Yuan ZM, Zhang B. 2019. Replication-Defective West Nile Virus with NS1 Deletion as a New Vaccine Platform for Flavivirus. J Virol, 93: e00720-19.
23. Li N, Zhang ZR, Zhang YN, Liu J, Deng CL, Shi PY, Yuan ZM, Ye HQ, Zhang B. 2020. A replication-defective Japanese encephalitis virus (JEV) vaccine candidate with NS1 deletion confers dual protection against JEV and West Nile virus in mice. NPJ Vaccines, 5: 73.
24. Loew-Baselli A, Poellabauer EM, Pavlova BG, Fritsch S, Firth C, Petermann R, Barrett PN, Ehrlich HJ. 2011. Prevention of tick-borne encephalitis by FSME-IMMUN vaccines: review of a clinical development programme. Vaccine, 29: 7307-7319.
25. Lotric-Furlan S, Bogovic P, Avsic-Zupanc T, Jelovsek M, Lusa L, Strle F. 2017. Tick-borne encephalitis in patients vaccinated against this disease. J Intern Med, 282: 142-155.
26. Lustig Y, Indenbaum V, Koren R, Katz-Likvornik S, Halpern O, Mendelson E. 2025. The diagnostic utility of Immunoglobulin G (IgG) avidity in distinguishing between past and acute infection of West Nile Virus (WNV). J Clin Microbiol, 63: e0095225.
27. Mandl CW, Holzmann H, Meixner T, Rauscher S, Stadler PF, Allison SL, Heinz FX. 1998. Spontaneous and engineered deletions in the 3' noncoding region of tick-borne encephalitis virus: construction of highly attenuated mutants of a flavivirus. J Virol, 72: 2132-2140.
28. Mandl CW, Kroschewski H, Allison SL, Kofler R, Holzmann H, Meixner T, Heinz FX. 2001. Adaptation of tick-borne encephalitis virus to BHK-21 cells results in the formation of multiple heparan sulfate binding sites in the envelope protein and attenuation in vivo. J Virol, 75: 5627-5637.
29. McAuley AJ, Sawatsky B, Ksiazek T, Torres M, Korva M, Lotric-Furlan S, Avsic-Zupanc T, von Messling V, Holbrook MR, Freiberg AN, Beasley DWC, Bente DA. 2017. Cross-neutralisation of viruses of the tick-borne encephalitis complex following tick-borne encephalitis vaccination and/or infection. NPJ Vaccines, 2: 5.
30. Perera DR, Ranadeva ND, Sirisena K, Wijesinghe KJ. 2024. Roles of NS1 Protein in Flavivirus Pathogenesis. ACS Infect Dis, 10: 20-56.
31. Puerta-Guardo H, Biering SB, Castillo-Rojas B, DiBiasio-White MJ, Lo NTN, Espinosa DA, Warnes CM, Wang C, Cao T, Glasner DR, Beatty PR, Kuhn RJ, Harris E. 2025. Flavivirus NS1-triggered endothelial dysfunction promotes virus dissemination. PLoS Pathog, 21: e1013811.
32. Pugh SJ, Moisi JC, Kundi M, Santonja I, Erber W, Angulo FJ, Jodar L. 2022. Effectiveness of two doses of tick-borne encephalitis (TBE) vaccine. J Travel Med, 29: taab193.
33. Pustijanac E, Bursic M, Talapko J, Skrlec I, Mestrovic T, Lisnjic D. 2023. Tick-Borne Encephalitis Virus: A Comprehensive Review of Transmission, Pathogenesis, Epidemiology, Clinical Manifestations, Diagnosis, and Prevention. Microorganisms, 11: 1634.
34. Srinivasan R, Angulo FJ, Duench S, Davidson A, Kelly PH, Riddle MS, Halsby K, Pilz A, Steffen R, Stark JH. 2025. Tick-borne encephalitis in international travellers: a systematic review and vaccine recommendations. J Travel Med, 32: taaf115.
35. Sui L, Wang W, Guo X, Zhao Y, Tian T, Zhang J, Wang H, Xu Y, Chi H, Xie H, Xu W, Liu N, Zhao L, Song G, Wang Z, Zhang K, Che L, Zhao Y, Wang G, Liu Q. 2024. Multi-protomics analysis identified host cellular pathways perturbed by tick-borne encephalitis virus infection. Nat Commun, 15: 10435.
36. Tang J, Fu M, Xu C, Xue B, Zhou A, Chen S, Zhao H, Zhou Y, Chen J, Yang Q, Chen X. 2023. Development of a novel virus-like particle-based vaccine for preventing tick-borne encephalitis virus infection. Virol Sin, 38: 767-777.
37. Venturi G, Martelli P, Mazzolini E, Fiorentini C, Benedetti E, Todone D, Villalta D, Fortuna C, Marchi A, Minelli G, Ciufolini MG. 2009. Humoral immunity in natural infection by tick-borne encephalitis virus. J Med Virol, 81: 665-671.
38. Youn S, Ambrose RL, Mackenzie JM, Diamond MS. 2013. Non-structural protein-1 is required for West Nile virus replication complex formation and viral RNA synthesis. Virol J, 10: 339.
39. Zhang HL, Ye HQ, Liu SQ, Deng CL, Li XD, Shi PY, Zhang B. 2017. West Nile Virus NS1 Antagonizes Interferon Beta Production by Targeting RIG-I and MDA5. J Virol, 91: e02396-16.
40. Zhang Q, Li N, Deng C, Zhang Z, Li X, Yoshii K, Ye H, Zhang B. 2019. Trans Complementation of Replication-defective Omsk Hemorrhagic Fever Virus for Antiviral Study. Virol Sin, 34: 412-422.
