Identification of PEDV inhibitors targeting 3CL protease

Ang Tian; Shutong Shi; Siying Zou; Shuaiyin Guan; Hao Wu; Zhen Li; Huanchun Chen; Yunfeng Song

doi:10.1016/j.virs.2025.06.002

August 2025

. doi: 10.1016/j.virs.2025.06.002

Citation: Ang Tian, Shutong Shi, Siying Zou, Shuaiyin Guan, Hao Wu, Zhen Li, Huanchun Chen, Yunfeng Song. Identification of PEDV inhibitors targeting 3CL protease .VIROLOGICA SINICA, 2025, 40(4) : 624-635. http://dx.doi.org/10.1016/j.virs.2025.06.002

以3CL蛋白酶为靶标鉴定PEDV抑制剂

田昂 ^a,b ,
石姝彤 ^a,b ,
邹思颖 ^a,b ,
关帅印 ^a,b ,
吴皓 ^a,b ,
李振 ^a,b ,
陈焕春 ^a,b ,
宋云峰 ^a,b,,

a 华中农业大学动物医学院, 武汉, 430070, 中国;
b 华中农业大学农业微生物资源发掘与利用全国重点实验室, 武汉, 430070, 中国

通讯作者： 宋云峰, syf@mail.hzau.edu.cn
收稿日期： 2025-02-18
录用日期： 2025-06-16

摘要

猪流行性腹泻（PED）由猪流行性腹泻病毒（PEDV）引起，是一种高度传染性的胃肠道疾病，其特征为呕吐、腹泻和脱水，对哺乳仔猪的致死率可接近100%。PEDV的3C样蛋白酶（3CLpro）对病毒复制至关重要，被视为开发抗病毒抑制剂的关键靶点。本研究旨在通过靶向3CLpro来筛选PEDV的小分子抑制剂。通过对ChemDiv化合物库中160万种化合物进行虚拟筛选，我们鉴定出四种潜在候选分子。分子动力学模拟（包括均方根偏差/RMSD、均方根涨落/RMSF、回转半径/Rg）分析表明，与单体酶相比，化合物-蛋白酶复合物的结构稳定性有所增强。所有化合物在Vero细胞中均表现出低细胞毒性（半数细胞毒性浓度/CC50 > 200 μM）。基于荧光共振能量转移（FRET）的活性测定显示，这些化合物对3CLpro具有剂量依赖性的抑制活性。在候选化合物中，F366-0161的抑制活性最弱，其半抑制浓度（IC50）为151.5 μM。其两个类似物3238-0395（IC50 = 121.4 μM）和L878-0493（IC50 = 123.6 μM）表现出中等程度的活性提升。Y041-1672被证实为最有效的抑制剂，其IC50为86.48 μM。在病毒复制抑制实验中，Y041-1672表现出抑制PEDV复制的能力，其半数有效浓度（EC50）达到17.97 μM，选择性指数（SI = CC50/EC50）为15.5。该化合物的抗病毒效果经RT-qPCR、空斑试验、免疫荧光和蛋白质印迹（Western blot）等多种方法验证。体外实验确认Y041-1672为最优抗病毒候选分子，加药时间点实验表明其抑制作用主要发生在病毒复制阶段。本研究成功筛选出可用于PEDV抗病毒药物开发的骨架分子，为猪流行性腹泻的治疗提供了策略性见解。
- 猪流行性腹泻病毒（PEDV）
- , 3CL蛋白酶
- , 虚拟筛选
- , 抗病毒

Identification of PEDV inhibitors targeting 3CL protease

Ang Tian ^a,b ,
Shutong Shi ^a,b ,
Siying Zou ^a,b ,
Shuaiyin Guan ^a,b ,
Hao Wu ^a,b ,
Zhen Li ^a,b ,
Huanchun Chen ^a,b ,
Yunfeng Song ^a,b,,

a. College of Veterinary Medicine, Huazhong Agricultural University, Wuhan, 430070, China;
b. National Key Laboratory of Agricultural Microbiology, Huazhong Agricultural University, Wuhan, 430070, China

Corresponding author: Yunfeng Song, syf@mail.hzau.edu.cn
Received Date: 18 February 2025
Accepted Date: 16 June 2025

Abstract

Porcine epidemic diarrhea (PED), caused by porcine epidemic diarrhea virus (PEDV), is a highly contagious gastrointestinal disease characterized by vomiting, diarrhea, and dehydration, with mortality rates approaching 100% among suckling piglets. The PEDV 3C-like protease (3CLpro) is essential for viral replication and regarded as a critical target for antiviral inhibitor development. In this study, we aimed to identify small-molecule inhibitors of PEDV by targeting 3CLpro. Virtual screening of 1.6 million compounds from the ChemDiv library identified four potential candidates. Molecular dynamics simulations, specifically analyzing RMSD, RMSF, and Rg, demonstrated increased structural stability of the compound-protease complexes compared to the monomeric enzyme. All compounds had low cytotoxicity in Vero cells (CC₅₀ > 200 μM). Fluorescence resonance energy transfer-based assays demonstrated dose-dependent inhibitory activity of the compounds against 3CLpro. Among the candidates, compound F366-0161 exhibited the weakest inhibition, with an IC₅₀ value of 151.5 μM. Two analogues, 3238-0395 (IC₅₀ of 121.4 μM) and L878-0493 (IC₅₀ of 123.6 μM), exhibited moderately enhanced activity. Y041-1672 was identified as the most effective inhibitor, with an IC₅₀ of 86.48 μM. In viral replication inhibition assays, Y041-1672 reduced PEDV replication, with an EC₅₀ of 17.97 μM and a selectivity index (SI) of 15.5 (CC₅₀/EC₅₀). These results were validated by RT-qPCR, plaque assays, immunofluorescence, and Western blot analyses. In vitro validation confirmed Y041-1672 as the optimal antiviral candidate, and time-of-addition experiments indicated that inhibition primarily occurred during viral replication. This study identifies scaffold molecules for PEDV antiviral drug development, providing strategic insights for PED treatment.
- Porcine epidemic diarrhea virus (PEDV)
- , 3CL protease
- , Virtual screening
- , Antiviral

References
1. Algar WR, Hildebrandt N, Vogel SS, Medintz IL. 2019. Fret as a biomolecular research tool - understanding its potential while avoiding pitfalls. Nat Methods, 16: 815-829.
2. Bahun M, Jukic M, Oblak D, Kranjc L, Bajc G, Butala M, Bozovicar K, Bratkovic T, Podlipnik C, Poklar Ulrih N. 2022. Inhibition of the sars-cov-2 3cl(pro) main protease by plant polyphenols. Food Chem, 373: 131594.
3. Bai B, Belovodskiy A, Hena M, Kandadai AS, Joyce MA, Saffran HA, Shields JA, Khan MB, Arutyunova E, Lu J, Bajwa SK, Hockman D, Fischer C, Lamer T, Vuong W, van Belkum MJ, Gu Z, Lin F, Du Y, Xu J, Rahim M, Young HS, Vederas JC, Tyrrell DL, Lemieux MJ, Nieman JA. 2022. Peptidomimetic alpha-acyloxymethylketone warheads with six-membered lactam p1 glutamine mimic: Sars-cov-2 3cl protease inhibition, coronavirus antiviral activity, and in vitro biological stability. J Med Chem, 65: 2905-2925.
4. Bowling NP, Speetzen ED, Bosch E. 2021. Arylethynyl helices supported by pi-stacking and halogen bonding. Chempluschem, 86: 745-749.
5. Brooks BR, Brooks CL, 3rd, Mackerell AD, Jr., Nilsson L, Petrella RJ, Roux B, Won Y, Archontis G, Bartels C, Boresch S, Caflisch A, Caves L, Cui Q, Dinner AR, Feig M, Fischer S, Gao J, Hodoscek M, Im W, Kuczera K, Lazaridis T, Ma J, Ovchinnikov V, Paci E, Pastor RW, Post CB, Pu JZ, Schaefer M, Tidor B, Venable RM, Woodcock HL, Wu X, Yang W, York DM, Karplus M. 2009. Charmm: The biomolecular simulation program. J Comput Chem, 30: 1545-1614.
6. Fargher HA, Sherbow TJ, Haley MM, Johnson DW, Pluth MD. 2022. C-hcdots, three dots, centereds hydrogen bonding interactions. Chem Soc Rev, 51: 1454-1469.
7. Faris A, Hadni H, Saleh BA, Khelfaoui H, Harkati D, Ait Ahsaine H, Elhallaoui M, El-Hiti GA. 2024. In silico screening of a series of 1,6-disubstituted 1h-pyrazolo[3,4-d]pyrimidines as potential selective inhibitors of the janus kinase 3. J Biomol Struct Dyn, 42: 4456-4474.
8. Huang J, MacKerell AD, Jr. 2013. Charmm36 all-atom additive protein force field: Validation based on comparison to nmr data. J Comput Chem, 34: 2135-2145.
9. Jablonski M. 2023. Hydrogen bonds. Molecules, 28: 1616.
10. Jo S, Kim T, Iyer VG, Im W. 2008. Charmm-gui: A web-based graphical user interface for charmm. J Comput Chem, 29: 1859-1865.
11. Jo S, Kim S, Shin DH, Kim MS. 2020. Inhibition of sars-cov 3cl protease by flavonoids. J Enzyme Inhib Med Chem, 35: 145-151.
12. Jung K, Saif LJ. 2015. Porcine epidemic diarrhea virus infection: Etiology, epidemiology, pathogenesis and immunoprophylaxis. Vet J, 204: 134-143.
13. Jung K, Saif LJ, Wang Q. 2020. Porcine epidemic diarrhea virus (pedv): An update on etiology, transmission, pathogenesis, and prevention and control. Virus Res, 286: 198045.
14. Kocherhans R, Bridgen A, Ackermann M, Tobler K. 2001. Completion of the porcine epidemic diarrhoea coronavirus (pedv) genome sequence. Virus Genes, 23: 137-144.
15. Langel SN, Wang Q, Vlasova AN, Saif LJ. 2020. Host factors affecting generation of immunity against porcine epidemic diarrhea virus in pregnant and lactating swine and passive protection of neonates. Pathogens, 9: 130.
16. Lee C. 2015. Porcine epidemic diarrhea virus: An emerging and re-emerging epizootic swine virus. Virol J, 12: 193.
17. Lee J, Cheng X, Swails JM, Yeom MS, Eastman PK, Lemkul JA, Wei S, Buckner J, Jeong JC, Qi Y, Jo S, Pande VS, Case DA, Brooks CL, 3rd, MacKerell AD, Jr., Klauda JB, Im W. 2016. Charmm-gui input generator for namd, gromacs, amber, openmm, and charmm/openmm simulations using the charmm36 additive force field. J Chem Theory Comput, 12: 405-413.
18. Leuner C, Dressman J. 2000. Improving drug solubility for oral delivery using solid dispersions. Eur J Pharm Biopharm, 50: 47-60.
19. Li W, Li H, Liu Y, Pan Y, Deng F, Song Y, Tang X, He Q. 2012. New variants of porcine epidemic diarrhea virus, china, 2011. Emerg Infect Dis, 18: 1350-1353.
20. Li Z, Cao H, Cheng Y, Zhang X, Zeng W, Sun Y, Chen S, He Q, Han H. 2020. Inhibition of porcine epidemic diarrhea virus replication and viral 3c-like protease by quercetin. Int J Mol Sci, 21: 8095.
21. Li Z, Zhu L, Wang L, Huang Y, Zhang Y, Zhao D, Wang L, Yi D, Hou Y, Wu T. 2024. Identification of two flavonoids antiviral inhibitors targeting 3c-like protease of porcine epidemic diarrhea virus. Front Microbiol, 15: 1357470.
22. Martinez MA. 2020. Compounds with therapeutic potential against novel respiratory 2019 coronavirus. Antimicrob Agents Chemother, 64: e00399-20.
23. Miao J, Yuan H, Rao J, Zou J, Yang K, Peng G, Cao S, Chen H, Song Y. 2022. Identification of a small compound that specifically inhibits zika virus in vitro and in vivo by targeting the ns2b-ns3 protease. Antiviral Res, 199: 105255.
24. Moon HW, Norman JO, Lambert G. 1973. Age dependent resistance to transmissible gastroenteritis of swine (tge). I. Clinical signs and some mucosal dimensions in small intestine. Can J Comp Med, 37: 157-166.
25. Niesor EJ, Boivin G, Rheaume E, Shi R, Lavoie V, Goyette N, Picard ME, Perez A, Laghrissi-Thode F, Tardif JC. 2021. Inhibition of the 3cl protease and sars-cov-2 replication by dalcetrapib. ACS Omega, 6: 16584-16591.
26. Pathak RK, Kim WI, Kim JM. 2023. Targeting the pedv 3cl protease for identification of small molecule inhibitors: An insight from virtual screening, admet prediction, molecular dynamics, free energy landscape, and binding energy calculations. J Biol Eng, 17: 29.
27. Resnick SJ, Iketani S, Hong SJ, Zask A, Liu H, Kim S, Melore S, Lin FY, Nair MS, Huang Y, Lee S, Tay NES, Rovis T, Yang HW, Xing L, Stockwell BR, Ho DD, Chavez A. 2021. Inhibitors of coronavirus 3cl proteases protect cells from protease-mediated cytotoxicity. J Virol, 95: e0237420.
28. Su M, Yin B, Xing X, Li Z, Zhang J, Feng S, Li L, Zhao F, Yang X, Yu S, Wang J, Zhang Y, Shi D, Chen J, Feng L, Guo D, Sun D. 2023. Octyl gallate targeting the 3c-like protease exhibits highly efficient antiviral activity against swine enteric coronavirus pedv. Vet Microbiol, 281: 109743.
29. Sun RQ, Cai RJ, Chen YQ, Liang PS, Chen DK, Song CX. 2012. Outbreak of porcine epidemic diarrhea in suckling piglets, china. Emerg Infect Dis, 18: 161-163.
30. Tian PF, Jin YL, Xing G, Qv LL, Huang YW, Zhou JY. 2014. Evidence of recombinant strains of porcine epidemic diarrhea virus, united states, 2013. Emerg Infect Dis, 20: 1735-1738.
31. Van Der Spoel D, Lindahl E, Hess B, Groenhof G, Mark AE, Berendsen HJ. 2005. Gromacs: Fast, flexible, and free. J Comput Chem, 26: 1701-1718.
32. Wang J, Tian WJ, Li CC, Zhang XZ, Fan K, Li SL, Wang XJ. 2022. Small-molecule raf265 as an antiviral therapy acts against pedv infection. Viruses, 14: 2261.
33. Wang P, Bai J, Liu X, Wang M, Wang X, Jiang P. 2020. Tomatidine inhibits porcine epidemic diarrhea virus replication by targeting 3cl protease. Vet Res, 51: 136.
34. Wang Y, Huang H, Li D, Zhao C, Li S, Qin P, Li Y, Yang X, Du W, Li W, Li Y. 2023. Identification of niclosamide as a novel antiviral agent against porcine epidemic diarrhea virus infection by targeting viral internalization. Virol Sin, 38: 296-308.
35. Werner JM, Serti E, Chepa-Lotrea X, Stoltzfus J, Ahlenstiel G, Noureddin M, Feld JJ, Liang TJ, Rotman Y, Rehermann B. 2014. Ribavirin improves the ifn-gamma response of natural killer cells to ifn-based therapy of hepatitis c virus infection. Hepatology, 60: 1160-1169.
36. Wood EN. 1977. An apparently new syndrome of porcine epidemic diarrhoea. Vet Rec, 100: 243-244.
37. Wu Y, Li M, Tian J, Yan H, Pan Y, Shi H, Shi D, Chen J, Guo L, Feng L. 2023. Broad antagonism of coronaviruses nsp5 to evade the host antiviral responses by cleaving poldip3. PLoS Pathog, 19: e1011702.
38. Zhang L, Lin D, Sun X, Curth U, Drosten C, Sauerhering L, Becker S, Rox K, Hilgenfeld R. 2020. Crystal structure of sars-cov-2 main protease provides a basis for design of improved alpha-ketoamide inhibitors. Science, 368: 409-412.
39. Zhang Y, Chen H, Zou M, Oerlemans R, Shao C, Ren Y, Zhang R, Huang X, Li G, Cong Y. 2021. Hypericin inhibit alpha-coronavirus replication by targeting 3cl protease. Viruses, 13: 1825.
40. Ziada S, Diharce J, Raimbaud E, Aci-Seche S, Ducrot P, Bonnet P. 2022. Estimation of drug-target residence time by targeted molecular dynamics simulations. J Chem Inf Model, 62: 5536-5549.
